BASICPARAMETERS

Pitch:	6mm
Rated voltage-UL:	300V
Rated current-UL:	10A
Rated voltage-IEC:	320V
Rated current-IEC:	17.5A
Wire range-UL:	20-16AWG
Wire range-IEC:	0.25-1.5mm²
Pole number:	2P、3P
Insulation Material:	PPA GF UL94 V-0
Contact material:	Copper alloy, tin plated
Wire stripping length:	7~10mm / 0.28~0.39inches
Operating temperature:	-60℃ ~ +105℃
Approval:

◆SMD PCB terminal block with push button and direct insertion cage spring (Push-in CAGE CLAMP ®) terminal unit

◆Both single stranded wires and wires with cold pressed joints can be directly inserted

◆Using a push button wiring method, it is easy to connect and remove almost all types of wires

◆Only 5.6 mm high

◆Roll up tape packaging, suitable for automatic assembly
